E36 Rear Trailing Arm Mount Reinforcement Plates
Fits:Ā All E36 Non-M, E36 M3 (Excluding Hatch)
Benefits:
-Reinforces theĀ Rear Trailing Arm (RTA) Mounts
-Prevents catastrophic suspension failure.
Note:Ā These products require welding to install.
Recommendations:Ā
-Pair this product with subframe mount reinforcement plates if not reinforced prior.
Material:Ā
-2.5mm 250MPa yield zinc coated mild steelĀ (zincanneal)
The E36 RTA mount differs from the E46 in that the mounting bracket bolts to individual stubs stitch welded into the sheet metal floor rather than a pressed metal pocket with a large perimeter flange. As a result, cracks are prone to form in the sheet metal about the perimeter of these welds resulting in the female threaded stubs separating from the chassis and thus the Rear Trailing Arm from the car.Ā
This plate provides the large perimeter flange that E36's need but, BMW didn't implement till the E46. This reinforcement will distribute the stress over a larger area to eliminate the potential for fatigue failure.Ā
Product Information
Product Information
Shipping & Returns
Shipping & Returns
E36 Rear Trailing Arm Mount Reinforcement Plates
E36 Rear Trailing Arm Mount Reinforcement Plates
Fits:Ā All E36 Non-M, E36 M3 (Excluding Hatch)
Benefits:
-Reinforces theĀ Rear Trailing Arm (RTA) Mounts
-Prevents catastrophic suspension failure.
Note:Ā These products require welding to install.
Recommendations:Ā
-Pair this product with subframe mount reinforcement plates if not reinforced prior.
Material:Ā
-2.5mm 250MPa yield zinc coated mild steelĀ (zincanneal)
The E36 RTA mount differs from the E46 in that the mounting bracket bolts to individual stubs stitch welded into the sheet metal floor rather than a pressed metal pocket with a large perimeter flange. As a result, cracks are prone to form in the sheet metal about the perimeter of these welds resulting in the female threaded stubs separating from the chassis and thus the Rear Trailing Arm from the car.Ā
This plate provides the large perimeter flange that E36's need but, BMW didn't implement till the E46. This reinforcement will distribute the stress over a larger area to eliminate the potential for fatigue failure.Ā
